SENTRON 3KC LCD 144x144 mm ATC6300 Intelligent Conversion Controller for MCCB ACB LBS

Name: SENTRON 3KC LCD 144x144 mm ATC6300 Intelligent Conversion Controller for MCCB ACB LBS
Brand: Siemens
Price: 1 USD

Quality SENTRON 3KC LCD 144x144 mm ATC6300 Intelligent Conversion Controller for MCCB ACB LBS for sale

Place of Origin : Italy

Brand Name : Siemens

Communication interface : Other

Brand : Siemens

Condition : 100% Original

Warranty : 12 Months

Package : Original Packaging

Shipping term : FOB

Payment : T/T

MOQ : 1pcs

Application : Automation Industrial

Quality : 100% strictly tested

Service : One-stop Service

Packaging Details : CARTONS

Price : $1,229.00/cartons 1-9 cartons

MOQ : 1 unit

Contact Now

SENTRON 3KC LCD 144x144 mm ATC6300 Intelligent Conversion Controller for MCCB ACB LBS

Specification

Model
product brand name			SENTRON
product designation			Accessories for transfer switching equipment
design of the product			3KC ATC6300
operating temperature
● minimum			-30 °C
● maximum			70 °C
switchover time of the control device			50 ms
overvoltage category			3
power frequency withstand voltage at auxiliary power supply at AC			3 000 V
operating period without auxiliary power supply			300 s
insulation voltage (Ui) at auxiliary power supply at AC rated value			250 V
impulse withstand voltage (Uimp) of the auxiliary power supply at AC rated value			6 000 V
interference immunity duration against voltage dip/sag at AC at 220 V
● without expansion modules maximum			250 ms
● with 1 expansion module maximum			180 ms
● with 2 expansion modules maximum			120 ms
supply voltage of the auxiliary power supply
● at AC initial rated value			100 V
● at AC final rated value			240 V
● at AC minimum			90 V
● at AC maximum			264 V
● at DC initial rated value			110 V
● at DC final rated value			250 V
● at DC minimum			93.5 V
● at DC maximum			300 V
supply voltage at DC power supply
● initial rated value			12 V
● final rated value			24 V
● minimum			7.5 V
● maximum			33 V
protection class IP
● on the front			IP40
● rear side			IP20
apparent power consumption at auxiliary power supply at AC at 240 V maximum			9.5 VA
power loss [W] at auxiliary power supply
● at AC at 240 V			3.8 W
● at DC at 250 V maximum			3.6 W
power loss [W] at DC power supply
● at 12 V maximum			3.2 W
● at 24 V maximum			2.9 W
operating frequency rated value
● minimum			45 Hz
● maximum			66 Hz
number of CO contacts for auxiliary contacts			1
number of NC contacts for auxiliary contacts			0
number of NO contacts for auxiliary contacts			6
product component of the hardware real time clock backup battery			Yes
product feature of enclosure material			Polycarbonate
accessories
number of slots			2
input current at digital input with signal <0> maximum			8 mA
number of digital inputs			6
● design of the switching input			Negative
output voltage at the relay outputs at AC maximum rated value			250 V
number of outputs as contact-affected switching element			7
output current at the relay outputs
● at AC-1 at 250 V rated value			8 A
● at AC-15 at 250 V rated value			1.5 A
● at DC-1 at 30 V rated value			8 A
type of contact rating according to NEMA			B300
switching capacity current at the relay outputs at DC at 30 V according to UL 508			1 A
mechanical service life (operating cycles) of the relay outputs			10 000 000
electrical endurance (operating cycles) of the relay outputs			100 000
input delay time			0.05 s
insulation voltage (Ui) of the relay outputs rated value			250 V
signal voltage
● for signal <0> at DC rated value			2 V
● for signal <1> at DC rated value			3.4 V
impulse withstand voltage (Uimp) of the relay outputs rated value			4 000 V
number of monitored phases			3
connectable conductor cross-section
● minimum			0.2 mm²
● maximum			2.5 mm²
connectable conductor cross-section according to UL 508
● minimum			0.75 mm²
● maximum			2.5 mm²
AWG number as coded connectable conductor cross section
● minimum			24
● maximum			12
AWG number as coded connectable conductor cross section according to UL 508
● minimum			18
● maximum			12
tightening torque [lbf·in] with screw-type terminals maximum			5 lbf·in
tightening torque with screw-type terminals maximum			0.56 N·m
type of electrical connection			Removable/plug-in
Mechanical Design
height			144 mm
width			144 mm
depth			43.3 mm
installation depth with expansion module maximum			73 mm
net weight			600 g
Environmental conditions
ambient temperature during storage
● minimum			-30 °C
● maximum			80 °C
